Product image is indicative only and provided as a guide.
Socomec
Socomec SLBM Load Break Switch kit, Base/DIN Rail mount, w/ Direct Handle, 3P 20A
- Item No.:
- SLBM203PD
- Product Range:
- SLBM
Download product datasheet
Electrical
- Rated permanent current at AC-21, 400 V
- 20 A
- Rated uninterrupted current Iu
- 20 A
- Number of poles
- 3
- Rated operation power at AC-23, 400 V
- 20 kW
- Rated operation current Ie at AC-23a, 400 V
- 20 A
- Rated operation current Ie at AC-23a, 500 V
- 20 A
- Rated operation current Ie at AC-23a, 690 V
- 20 A
- Rated short-time withstand current lcw
- 2.5 kA
- Rated insulation voltage Ui
- 800 V
Mechanical
- Padlock locking
- Yes
Dimensions
- Height
- 75 mm
- Width
- 45 mm
- Depth
- 75 mm
- Weight
- 0.16 kg
- Conductor cross section (solid, stranded)
- 1.5-16 mm²
- Connectable conductor cross section
- 1.5-16 mm²
Construction
- Degree of protection (IP), front side
- IP65
- Version as main switch
- Yes
- Version as reversing switch
- No
- Number of switches
- 1
- Suitable for front mounting 4-hole
- No
- Suitable for front mounting centre
- No
- Suitable for distribution board installation
- Yes
- Suitable for intermediate mounting
- No
- Interlockable
- Yes
