Product image is indicative only and provided as a guide.
Carlo Gavazzi
Carlo Gavazzi Photoelectric Sensor Diffuse Reflective Back Suppresion NPN NO NC M8 Range-.15m 5m
- Item No.:
- PD30CNB15NPM5RT
- Product Range:
- Photoelectric Sensor
Download product datasheet
Photometric
- Sensing type
- Background suppression
- Type of light
- Laser diode, red light
- Wavelength of the sensor
- 660 nm
- Max. switching distance
- 150 mm
Construction
- Material of optical surface
- Plastic
- Material housing
- Plastic
- Construction type housing
- Cuboid
- IP rating
- IP67
- Suitable for safety functions
- No
Dimensions
- Width sensor
- 10 mm
- Height of sensor
- 30 mm
Electrical
- Setting procedure
- Manual adjustment
- Voltage type
- DC
- Rated control supply voltage Us at DC
- 18-30 V
- Type of switch function
- Change-over contact (NO/NC)
- Type of switching output
- NPN
- Switching frequency
- 1000 Hz
- Type of electric connection
- Connector M8
- Max. output current
- 100 mA
Environment
- Ambient temperature
- -25...55 °C
Mechanical
- With time function
- No
