Cirprotec

Cirprotec Final Diverters SPD Comm Fine Protect 6V

Item No. CPTDIN6V2C
Product Range: Final Diverter
Component Type (ETIM Class)
Surge protection device for data networks/MCR-technology
Electrical
Nominal voltage AC6 V
Max. continuous voltage AC7 V
Nominal discharge surge current (8/20)5 kA
Max. discharge surge current (8/20)10 kA
Lightning impulse current (10/350 µs)10 kA
Voltage protection level core/earth10 V
Frequency1000000 MHz
Number of protected wiresOther
Construction
Mounting methodDIN rail (top hat rail) 35 mm
Degree of protection (IP)IP20
Dimensions
Max. conductor cross section2.5 mm²
Height90 mm
Width17.5 mm
Depth70 mm
Weight0.06 kg
