Carlo Gavazzi
Carlo Gavazzi Level Sensor Level Controller 24V AC DC 2 Points DPDT Relay Output DIN
- Item No.:
- CLD2EA1CM24
- Product Range:
- Level Sensor
Download product datasheet
Construction
- Suitable for plug-in socket mounting
- No
- Suitable for DIN rail mounting
- Yes
- Material contact
- Silver cadmium-oxide
- IP rating
- IP20
- Number of inputs for electrodes
- 2
Electrical
- Rated operation current Ie
- 8 A
- Rated operation current Ie at AC-15, 230 V
- 0.4 A
- Response value sensitivity adjustable
- Yes
- Number of contacts as change-over contact
- 2
- Min. adjustable off-delay time
- 1 s
- Max. permitted off-delay time
- 1 s
- Min. adjustable operate delay time
- 1 s
- Max. permitted operate delay time
- 1 s
- Voltage type for actuating
- AC/DC
Dimensions
- Weight
- 0.13 kg
- Height
- 81 mm
- Width
- 35.5 mm
- Depth
- 60.2 mm
Environment
- Rated temperature
- -20...50 °C
Mechanical
- Physical measurement principle
- Conductive
