Product image is indicative only and provided as a guide.
Allen-Bradley
Allen-Bradley 700-HL Solid State Interface Relay 10A 2CO 220 to 240VAC DC Standard Silver Contacts
- Item No.:
- 700HLT12U2
- Product Range:
- 700HLT
Download product datasheet
Electrical
- Nominal current
- 10 A
- Nominal voltage AC
- 250 V
- Number of contacts as change-over contact
- 2
- Rated switching power at AC-1
- 2500 VA
- Rated switching power at AC-15, 230V
- 690 VA
- Breaking capacity at DC-1, 30V
- 10 A
- Voltage type for actuating
- AC/DC
- Control supply voltage Us at AC 50HZ
- 240 V
- Rated control supply voltage Us at AC 50HZ
- 220240 V
Construction
- Material contact
- Silver tin-oxide
- Complete with socket
- Yes
- Suitable for plug-in socket mounting
- Yes
- IP rating
- IP20
Dimensions
- Width
- 6.2 mm
- Height
- 88 mm
- Depth
- 76 mm
Mechanical
- Mechanical life (service cycles)
- 10000000 cycles
Environment
- Operating temperature
- -40...55 °C
