nVent ERIFLEX

nVent ERIFLEX Distribution Blocks 715A In 1 x 95 to 240mm Out 6 x 10 to 50mm Aluminium

Item No. 569201
Product Range: Distribution Block
Component Type (ETIM Class)
Distributor assembly terminal blocks
Electrical
Number of poles1
Rated insulation voltage Ui1000 V
Short time withstand current Icw, 1 sec34.3 kA
Max. rated current500 A
Construction
Conductor materialAluminium/copper
With PE-railNo
With N-railNo
Dimensions
Conductor cross section solid (solid, stranded)50-10 mm²
Height90 mm
Width44 mm
Depth148 mm
