Socomec
Socomec Digiware U-10 3Ph Voltage Reference Module for Energy Meter
Item No. 48290105
Product Range: Digiware U
Component Type (ETIM Class)
Multifunction measuring instrument
Electrical
Pole typeThree conductor/four conductor
VoltmeterYes
Ampere meterNo
Pulse counterNo
Frequency meterYes
Effective power measurement deviceNo
Accuracy class active energy according to IEC 62053-22Other
Accuracy class reactive energy according to IEC 62053-23Other
Voltage type of supply voltageDC
Communication
Supporting protocol for other bus systemsNo
Supporting protocol for ModbusYes
Supporting protocol for BACnetNo
Web server with HTTPS transfer protocolNo
Supporting protocol for IEC 61850 EthernetNo
Supporting protocol for OPC UA PubSubNo
Supporting protocol for PROFIBUSNo
Supporting protocol for PROFINET IONo
With firmware signatureYes
Construction
ModelMeasurement transformer
Number of analogue inputs0
Number of analogue outputs0
Number of digital inputs0
Number of digital outputs0
Mounting methodDIN rail
Degree of protection (IP), front sideIP40
Mechanical
DisplayNone
Remote displayNo
Connection systemScrewed terminal
With rotational speed meterNo
Dimensions
Depth65 mm
Width18 mm
Height90 mm
Environment
Operating temperature-10-70
Storage temperature-25-70 °C
