Product image is indicative only and provided as a guide.
Allen-Bradley
Allen-Bradley 1606 Power Supply Compact 1Phase 100 to 240V AC to 24 to 28V DC 100W 4.2A
- Item No.:
- 1606XLP100E
- Product Range:
- 1606
Download product datasheet
Electrical
- Voltage type of supply voltage
- AC/DC
- Rated supply voltage at AC 50 Hz
- 100-240 V
- Rated supply voltage at DC
- 220-375 V
- Frequency
- 50-60 Hz
- Nominal current (In)
- 1 A
- Max. starting current
- 37 A
- 1st secondary output voltage
- 24-28 V
- Max. output current 1
- 4.2 A
- Nominal value output current 1
- 4.2 A
Construction
- Rail mounting possible
- Yes
- Wall mounting possible
- Yes
- IP rating
- IP20
- Direct mounting possible
- No
- Degree of protection (NEMA)
- Other
Dimensions
- Width
- 73 mm
- Height
- 75 mm
- Depth
- 103 mm
- Weight
- 0.36 kg
Environment
- Operating temperature
- -10...70 °C
- Stabilized
- Yes
